载体基本信息

出品公司: --
载体名称: pKD46
质粒类型: 细菌表达;基因敲除系统
高拷贝/低拷贝: --
启动子: --
克隆方法: 多克隆位点,限制性内切酶
载体大小: 6329 bp
5' 测序引物及序列: --
3' 测序引物及序列: --
载体标签: --
载体抗性: --
筛选标记: --
备注: pKD46 is more efficient than pKD20 for making gene disruptions.
产品目录号: --
稳定性: --
组成型: --
病毒/非病毒: --

载体质粒图谱和多克隆位点信息

pCMV-Tag3B载体图谱

载体简介

载体序列

LOCUS       pKD46                6329 bp    DNA     circular SYN 11-SEP-2001
DEFINITION  Red recombinase plasmid pKD46, complete sequence.
ACCESSION   AY048746
VERSION     AY048746.1  GI:15554345
KEYWORDS    .
SOURCE      Red recombinase plasmid pKD46
  ORGANISM  Red recombinase plasmid pKD46
            other sequences; artificial sequences; vectors.
REFERENCE   1  (bases 1 to 6329)
  AUTHORS   Datsenko,K.A. and Wanner,B.L.
  TITLE     One-step inactivation of chromosomal genes in Escherichia coli K-12
            using PCR products
  JOURNAL   Proc. Natl. Acad. Sci. U.S.A. 97 (12), 6640-6645 (2000)
   PUBMED   10829079
REFERENCE   2  (bases 1 to 6329)
  AUTHORS   Datsenko,K.A. and Wanner,B.L.
  TITLE     Direct Submission
  JOURNAL   Submitted (29-JUL-2001) Biological Sciences, Purdue University,
            Lilly Hall of Life Sciences, West Lafayette, IN 47907, USA
FEATURES             Location/Qualifiers
     source          1..6329
                     /organism="Red recombinase plasmid pKD46"
                     /mol_type="genomic DNA"
                     /db_xref="taxon:170495"
     CDS             complement(11..889)
                     /codon_start=1
                     /transl_table=11
                     /product="araC protein"
                     /protein_id="AAL02045.1"
                     /db_xref="GI:15554346"
     misc_feature    complement(1040..1068)
                     /note="Pc"
     misc_feature    1165..1192
                     /note="ParaB"
     CDS             1244..1660
                     /note="recombination;138"
                     /codon_start=1
                     /transl_table=11
                     /product="gam protein"
                     /protein_id="AAL02046.1"
                     /db_xref="GI:15554347"
     CDS             1666..2451
                     /note="recombination;261"
                     /codon_start=1
                     /transl_table=11
                     /product="bet protein"
                     /protein_id="AAL02047.1"
                     /db_xref="GI:15554348"
     CDS             2448..3128
                     /note="exo"
                     /codon_start=1
                     /transl_table=11
                     /product="exonuclease"
                     /protein_id="AAL02048.1"
                     /db_xref="GI:15554349"
     misc_feature    3118..3387
                     /note="tL3"
     CDS             3125..3307
                     /note="60a"
                     /codon_start=1
                     /transl_table=11
                     /product="orf60a protein"
                     /protein_id="AAL02051.1"
                     /db_xref="GI:15554352"
     CDS             complement(3496..4446)
                     /codon_start=1
                     /transl_table=11
                     /product="repA101 protein"
                     /protein_id="AAL02049.1"
                     /db_xref="GI:15554350"
     rep_origin      4450..5190
                     /note="oriR101"
     CDS             complement(5338..6198)
                     /note="bla; ampicillin resistance"
                     /codon_start=1
                     /transl_table=11
                     /product="beta-lactamase"
                     /protein_id="AAL02050.1"
                     /db_xref="GI:15554351"
ORIGIN
        1 catcgattta ttatgacaac ttgacggcta catcattcac tttttcttca caaccggcac
       61 ggaactcgct cgggctggcc ccggtgcatt ttttaaatac ccgcgagaaa tagagttgat
      121 cgtcaaaacc aacattgcga ccgacggtgg cgataggcat ccgggtggtg ctcaaaagca
      181 gcttcgcctg gctgatacgt tggtcctcgc gccagcttaa gacgctaatc cctaactgct
      241 ggcggaaaag atgtgacaga cgcgacggcg acaagcaaac atgctgtgcg acgctggcga
      301 tatcaaaatt gctgtctgcc aggtgatcgc tgatgtactg acaagcctcg cgtacccgat
      361 tatccatcgg tggatggagc gactcgttaa tcgcttccat gcgccgcagt aacaattgct
      421 caagcagatt tatcgccagc agctccgaat agcgcccttc cccttgcccg gcgttaatga
      481 tttgcccaaa caggtcgctg aaatgcggct ggtgcgcttc atccgggcga aagaaccccg
      541 tattggcaaa tattgacggc cagttaagcc attcatgcca gtaggcgcgc ggacgaaagt
      601 aaacccactg gtgataccat tcgcgagcct ccggatgacg accgtagtga tgaatctctc
      661 ctggcgggaa cagcaaaata tcacccggtc ggcaaacaaa ttctcgtccc tgatttttca
      721 ccaccccctg accgcgaatg gtgagattga gaatataacc tttcattccc agcggtcggt
      781 cgataaaaaa atcgagataa ccgttggcct caatcggcgt taaacccgcc accagatggg
      841 cattaaacga gtatcccggc agcaggggat cattttgcgc ttcagccata cttttcatac
      901 tcccgccatt cagagaagaa accaattgtc catattgcat cagacattgc cgtcactgcg
      961 tcttttactg gctcttctcg ctaaccaaac cggtaacccc gcttattaaa agcattctgt
     1021 aacaaagcgg gaccaaagcc atgacaaaaa cgcgtaacaa aagtgtctat aatcacggca
     1081 gaaaagtcca cattgattat ttgcacggcg tcacactttg ctatgccata gcatttttat
     1141 ccataagatt agcggatcct acctgacgct ttttatcgca actctctact gtttctccat
     1201 acccgttttt ttgggaattc gagctctaag gaggttataa aaaatggata ttaatactga
     1261 aactgagatc aagcaaaagc attcactaac cccctttcct gttttcctaa tcagcccggc
     1321 atttcgcggg cgatattttc acagctattt caggagttca gccatgaacg cttattacat
     1381 tcaggatcgt cttgaggctc agagctgggc gcgtcactac cagcagctcg cccgtgaaga
     1441 gaaagaggca gaactggcag acgacatgga aaaaggcctg ccccagcacc tgtttgaatc
     1501 gctatgcatc gatcatttgc aacgccacgg ggccagcaaa aaatccatta cccgtgcgtt
     1561 tgatgacgat gttgagtttc aggagcgcat ggcagaacac atccggtaca tggttgaaac
     1621 cattgctcac caccaggttg atattgattc agaggtataa aacgaatgag tactgcactc
     1681 gcaacgctgg ctgggaagct ggctgaacgt gtcggcatgg attctgtcga cccacaggaa
     1741 ctgatcacca ctcttcgcca gacggcattt aaaggtgatg ccagcgatgc gcagttcatc
     1801 gcattactga tcgttgccaa ccagtacggc cttaatccgt ggacgaaaga aatttacgcc
     1861 tttcctgata agcagaatgg catcgttccg gtggtgggcg ttgatggctg gtcccgcatc
     1921 atcaatgaaa accagcagtt tgatggcatg gactttgagc aggacaatga atcctgtaca
     1981 tgccggattt accgcaagga ccgtaatcat ccgatctgcg ttaccgaatg gatggatgaa
     2041 tgccgccgcg aaccattcaa aactcgcgaa ggcagagaaa tcacggggcc gtggcagtcg
     2101 catcccaaac ggatgttacg tcataaagcc atgattcagt gtgcccgtct ggccttcgga
     2161 tttgctggta tctatgacaa ggatgaagcc gagcgcattg tcgaaaatac tgcatacact
     2221 gcagaacgtc agccggaacg cgacatcact ccggttaacg atgaaaccat gcaggagatt
     2281 aacactctgc tgatcgccct ggataaaaca tgggatgacg acttattgcc gctctgttcc
     2341 cagatatttc gccgcgacat tcgtgcatcg tcagaactga cacaggccga agcagtaaaa
     2401 gctcttggat tcctgaaaca gaaagccgca gagcagaagg tggcagcatg acaccggaca
     2461 ttatcctgca gcgtaccggg atcgatgtga gagctgtcga acagggggat gatgcgtggc
     2521 acaaattacg gctcggcgtc atcaccgctt cagaagttca caacgtgata gcaaaacccc
     2581 gctccggaaa gaagtggcct gacatgaaaa tgtcctactt ccacaccctg cttgctgagg
     2641 tttgcaccgg tgtggctccg gaagttaacg ctaaagcact ggcctgggga aaacagtacg
     2701 agaacgacgc cagaaccctg tttgaattca cttccggcgt gaatgttact gaatccccga
     2761 tcatctatcg cgacgaaagt atgcgtaccg cctgctctcc cgatggttta tgcagtgacg
     2821 gcaacggcct tgaactgaaa tgcccgttta cctcccggga tttcatgaag ttccggctcg
     2881 gtggtttcga ggccataaag tcagcttaca tggcccaggt gcagtacagc atgtgggtga
     2941 cgcgaaaaaa tgcctggtac tttgccaact atgacccgcg tatgaagcgt gaaggcctgc
     3001 attatgtcgt gattgagcgg gatgaaaagt acatggcgag ttttgacgag atcgtgccgg
     3061 agttcatcga aaaaatggac gaggcactgg ctgaaattgg ttttgtattt ggggagcaat
     3121 ggcgatgacg catcctcacg ataatatccg ggtaggcgca atcactttcg tctactccgt
     3181 tacaaagcga ggctgggtat ttcccggcct ttctgttatc cgaaatccac tgaaagcaca
     3241 gcggctggct gaggagataa ataataaacg aggggctgta tgcacaaagc atcttctgtt
     3301 gagttaagaa cgagtatcga gatggcacat agccttgctc aaattggaat caggtttgtg
     3361 ccaataccag tagaaacaga cgaagaatcc atgggtatgg acagttttcc ctttgatatg
     3421 taacggtgaa cagttgttct acttttgttt gttagtcttg atgcttcact gatagataca
     3481 agagccataa gaacctcaga tccttccgta tttagccagt atgttctcta gtgtggttcg
     3541 ttgtttttgc gtgagccatg agaacgaacc attgagatca tacttacttt gcatgtcact
     3601 caaaaatttt gcctcaaaac tggtgagctg aatttttgca gttaaagcat cgtgtagtgt
     3661 ttttcttagt ccgttacgta ggtaggaatc tgatgtaatg gttgttggta ttttgtcacc
     3721 attcattttt atctggttgt tctcaagttc ggttacgaga tccatttgtc tatctagttc
     3781 aacttggaaa atcaacgtat cagtcgggcg gcctcgctta tcaaccacca atttcatatt
     3841 gctgtaagtg tttaaatctt tacttattgg tttcaaaacc cattggttaa gccttttaaa
     3901 ctcatggtag ttattttcaa gcattaacat gaacttaaat tcatcaaggc taatctctat
     3961 atttgccttg tgagttttct tttgtgttag ttcttttaat aaccactcat aaatcctcat
     4021 agagtatttg ttttcaaaag acttaacatg ttccagatta tattttatga atttttttaa
     4081 ctggaaaaga taaggcaata tctcttcact aaaaactaat tctaattttt cgcttgagaa
     4141 cttggcatag tttgtccact ggaaaatctc aaagccttta accaaaggat tcctgatttc
     4201 cacagttctc gtcatcagct ctctggttgc tttagctaat acaccataag cattttccct
     4261 actgatgttc atcatctgag cgtattggtt ataagtgaac gataccgtcc gttctttcct
     4321 tgtagggttt tcaatcgtgg ggttgagtag tgccacacag cataaaatta gcttggtttc
     4381 atgctccgtt aagtcatagc gactaatcgc tagttcattt gctttgaaaa caactaattc
     4441 agacatacat ctcaattggt ctaggtgatt ttaatcacta taccaattga gatgggctag
     4501 tcaatgataa ttactagtcc ttttcctttg agttgtgggt atctgtaaat tctgctagac
     4561 ctttgctgga aaacttgtaa attctgctag accctctgta aattccgcta gacctttgtg
     4621 tgtttttttt gtttatattc aagtggttat aatttataga ataaagaaag aataaaaaaa
     4681 gataaaaaga atagatccca gccctgtgta taactcacta ctttagtcag ttccgcagta
     4741 ttacaaaagg atgtcgcaaa cgctgtttgc tcctctacaa aacagacctt aaaaccctaa
     4801 aggcttaagt agcaccctcg caagctcggt tgcggccgca atcgggcaaa tcgctgaata
     4861 ttccttttgt ctccgaccat caggcacctg agtcgctgtc tttttcgtga cattcagttc
     4921 gctgcgctca cggctctggc agtgaatggg ggtaaatggc actacaggcg ccttttatgg
     4981 attcatgcaa ggaaactacc cataatacaa gaaaagcccg tcacgggctt ctcagggcgt
     5041 tttatggcgg gtctgctatg tggtgctatc tgactttttg ctgttcagca gttcctgccc
     5101 tctgattttc cagtctgacc acttcggatt atcccgtgac aggtcattca gactggctaa
     5161 tgcacccagt aaggcagcgg tatcatcaac ggggtctgac gctcagtgga acgaaaactc
     5221 acgttaaggg attttggtca tgagattatc aaaaaggatc ttcacctaga tccttttaaa
     5281 ttaaaaatga agttttaaat caatctaaag tatatatgag taaacttggt ctgacagtta
     5341 ccaatgctta atcagtgagg cacctatctc agcgatctgt ctatttcgtt catccatagt
     5401 tgcctgactc cccgtcgtgt agataactac gatacgggag ggcttaccat ctggccccag
     5461 tgctgcaatg ataccgcgag acccacgctc accggctcca gatttatcag caataaacca
     5521 gccagccgga agggccgagc gcagaagtgg tcctgcaact ttatccgcct ccatccagtc
     5581 tattaattgt tgccgggaag ctagagtaag tagttcgcca gttaatagtt tgcgcaacgt
     5641 tgttgccatt gctacaggca tcgtggtgtc acgctcgtcg tttggtatgg cttcattcag
     5701 ctccggttcc caacgatcaa ggcgagttac atgatccccc atgttgtgca aaaaagcggt
     5761 tagctccttc ggtcctccga tcgttgtcag aagtaagttg gccgcagtgt tatcactcat
     5821 ggttatggca gcactgcata attctcttac tgtcatgcca tccgtaagat gcttttctgt
     5881 gactggtgag tactcaacca agtcattctg agaatagtgt atgcggcgac cgagttgctc
     5941 ttgcccggcg tcaatacggg ataataccgc gccacatagc agaactttaa aagtgctcat
     6001 cattggaaaa cgttcttcgg ggcgaaaact ctcaaggatc ttaccgctgt tgagatccag
     6061 ttcgatgtaa cccactcgtg cacccaactg atcttcagca tcttttactt tcaccagcgt
     6121 ttctgggtga gcaaaaacag gaaggcaaaa tgccgcaaaa aagggaataa gggcgacacg
     6181 gaaatgttga atactcatac tcttcctttt tcaatattat tgaagcattt atcagggtta
     6241 ttgtctcatg agcggataca tatttgaatg tatttagaaa aataaacaaa taggggttcc
     6301 gcgcacattt ccccgaaaag tgccacctg
//

载体质粒图谱pdf版和相关资料下载

载体应用举例
