pH2B-mfRFP-N1

LOCUS      pH2B-mfRFP-N1           5115 bp DNA     circular SYN 26-DEC-2023
DEFINITION  Localization: Nucleus/Histones, Excitation: 383, Emission: 448.
ACCESSION   .
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 5115)
  TITLE     Davidson Blue Fluorescent Proteins
REFERENCE   2  (bases 1 to 5115)
  AUTHORS   .
  TITLE     Direct Submission
  JOURNAL   Exported Jul 6, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
COMMENT     SGRef: number: 1; type: "Journal Article"
FEATURES             Location/Qualifiers
     source          1..5115
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     enhancer        68..371
                     /label=CMV enhancer
                     /note="human cytomegalovirus immediate early enhancer"
     promoter        372..575
                     /label=CMV promoter
                     /note="human cytomegalovirus (CMV) immediate early
                     promoter"
     primer_bind     526..546
                     /label=CMV-F
                     /note="Human CMV immediate early promoter, forward primer"
     CDS             664..1041
                     /codon_start=1
                     /gene="HIST1H2BJ"
                     /product="human histone H2B"
                     /label=H2B
                     /translation="MPEPAKSAPAPKKGSKKAVTKAQKKGGKKRKRSRKESYSIYVYKV
                     LKQVHPDTGISSKAMGIMNSFVNDIFERIAGEASRLAHYNKRSTITSREIQTAVRLLLP
                     GELAKHAVSEGTKAITKYTSAK"
     primer_bind     901..921
                     /label=H2B-F
     CDS             1054..1785
                     /codon_start=1
                     /label=mfRFP
                     /translation="MVSKGEELIKENMPLKLYMEGTVNNHHFKCTAEGEGKPYEGTQTQ
                     RIKVVEGGPLPFAFDILATSFMYGSHTFIDHTPGIPDFWKQSFPEGFTWERVTTYEDGG
                     VLIATQDTSLHDGCLIYNVKLRGVNFPSNGPVMQKKTLGWEAHTELLYPTDGGLEGRTA
                     LALKLVGGGHLLCNFKTIYRSKKPAKNLKMPGVYYVDYRLERIEEADNETYVEQHEVAV
                     ARYCDLPTKLGHKLKGMDELYK"
     misc_feature    1537..1539
                     /label=T162A
     polyA_signal    1910..2031
                     /label=SV40 poly(A) signal
                     /note="SV40 polyadenylation signal"
     primer_bind     complement(1947..1966)
                     /label=SV40pA-R
                     /note="SV40 polyA, reverse primer"
     primer_bind     2001..2020
                     /label=EBV-rev
                     /note="SV40 polyA terminator, reverse primer"
     rep_origin      complement(2038..2493)
                     /direction=LEFT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     primer_bind     complement(2175..2196)
                     /label=F1ori-F
                     /note="F1 origin, forward primer"
     primer_bind     2387..2406
                     /label=F1ori-R
                     /note="F1 origin, reverse primer"
     promoter        2520..2624
                     /gene="bla"
                     /label=AmpR promoter
     promoter        2626..2983
                     /label=SV40 promoter
                     /note="SV40 enhancer and early promoter"
     primer_bind     complement(2649..2669)
                     /label=pBABE 3'
                     /note="SV40 enhancer, reverse primer for pBABE vectors"
     rep_origin      2834..2969
                     /label=SV40 ori
                     /note="SV40 origin of replication"
     primer_bind     2896..2915
                     /label=SV40pro-F
                     /note="SV40 promoter/origin, forward primer"
     primer_bind     complement(2919..2930)
                     /label=SV40pro-F
                     /note="SV40 promoter/origin, forward primer"
     CDS             3018..3812
                     /codon_start=1
                     /gene="aph(3')-II (or nptII)"
                     /product="aminoglycoside phosphotransferase from Tn5"
                     /label=NeoR/KanR
                     /note="confers resistance to neomycin, kanamycin, and G418
                     (Geneticin(R))"
                     /translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGRP
                     VLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDLLS
                     SHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDEEHQ
                     GLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRYQDIA
                     LATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF"
     primer_bind     complement(3072..3091)
                     /label=Neo-R
                     /note="Neomycin resistance gene, reverse primer"
     primer_bind     3682..3701
                     /label=Neo-F
                     /note="Neomycin resistance gene, forward primer"
     primer_bind     complement(4000..4019)
                     /label=TK-pA-R
                     /note="Thymidine kinase polyA, reverse primer"
     polyA_signal    4044..4091
                     /label=HSV TK poly(A) signal
                     /note="herpes simplex virus thymidine kinase
                     polyadenylation signal (Cole and Stacy, 1985)"
     rep_origin      4420..5008
                     /direction=RIGHT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
     primer_bind     4909..4928
                     /label=pBR322ori-F
                     /note="pBR322 origin, forward primer"
ORIGIN
        1 catgcattag ttattaatag taatcaatta cggggtcatt agttcatagc ccatatatgg
       61 agttccgcgt tacataactt acggtaaatg gcccgcctgg ctgaccgccc aacgaccccc
      121 gcccattgac gtcaataatg acgtatgttc ccatagtaac gccaataggg actttccatt
      181 gacgtcaatg ggtggagtat ttacggtaaa ctgcccactt ggcagtacat caagtgtatc
      241 atatgccaag tacgccccct attgacgtca atgacggtaa atggcccgcc tggcattatg
      301 cccagtacat gaccttatgg gactttccta cttggcagta catctacgta ttagtcatcg
      361 ctattaccat ggtgatgcgg ttttggcagt acatcaatgg gcgtggatag cggtttgact
      421 cacggggatt tccaagtctc caccccattg acgtcaatgg gagtttgttt tggcaccaaa
      481 atcaacggga ctttccaaaa tgtcgtaaca actccgcccc attgacgcaa atgggcggta
      541 ggcgtgtacg gtgggaggtc tatataagca gagctggttt agtgaaccgt cagatccgct
      601 agcgctaccg gactcagatc tcgagctcaa gcttcgaatt ctgcagtcga cggtaccgcc
      661 accatgccag agccagcgaa gtctgctccc gccccgaaaa agggctccaa gaaggcggtg
      721 actaaggcgc agaagaaagg cggcaagaag cgcaagcgca gccgcaagga gagctattcc
      781 atctatgtgt acaaggttct gaagcaggtc caccctgaca ccggcatttc gtccaaggcc
      841 atgggcatca tgaattcgtt tgtgaacgac attttcgagc gcatcgcagg tgaggcttcc
      901 cgcctggcgc attacaacaa gcgctcgacc atcacctcca gggagatcca gacggccgtg
      961 cgcctgctgc tgcctgggga gttggccaag cacgccgtgt ccgagggtac taaggccatc
     1021 accaagtaca ccagcgctaa ggatccaccg gtgatggtga gcaagggcga ggagctgatt
     1081 aaggagaaca tgccactgaa gctgtacatg gagggcaccg ttaacaatca ccacttcaag
     1141 tgcacagctg agggcgaagg caagccctac gagggcaccc agacccagag aatcaaggtg
     1201 gtcgagggcg gccctctccc cttcgccttc gacatcctgg ctaccagttt catgtacggc
     1261 agtcacacct tcatcgacca caccccgggc atccccgact tctggaagca gtccttcccc
     1321 gagggcttca cgtgggagag agtcaccaca tacgaagacg ggggcgtcct gatcgcgacc
     1381 caggacacca gcctccatga cggctgcctc atctacaacg tcaagttgag aggggtgaac
     1441 ttcccatcca acggccctgt gatgcaaaag aaaacactcg gctgggaggc acacaccgag
     1501 cttttgtacc ccactgacgg cggtctggaa ggcagaaccg cgctggccct gaagcttgtg
     1561 ggcgggggcc acctattgtg taacttcaag actatataca gatccaagaa acccgctaag
     1621 aacctcaaga tgcccggcgt ctactatgtg gactacagac tggaaagaat cgaggaggcc
     1681 gacaatgaga cctacgtcga gcagcacgag gtggctgtgg ccagatactg cgacctccct
     1741 accaaactgg ggcacaagct taagggcatg gacgagctgt acaagtaggc ggccgcgact
     1801 ctagatcata atcagccata ccacatttgt agaggtttta cttgctttaa aaaacctccc
     1861 acacctcccc ctgaacctga aacataaaat gaatgcaatt gttgttgtta acttgtttat
     1921 tgcagcttat aatggttaca aataaagcaa tagcatcaca aatttcacaa ataaagcatt
     1981 tttttcactg cattctagtt gtggtttgtc caaactcatc aatgtatctt aaggcgtaaa
     2041 ttgtaagcgt taatattttg ttaaaattcg cgttaaattt ttgttaaatc agctcatttt
     2101 ttaaccaata ggccgaaatc ggcaaaatcc cttataaatc aaaagaatag accgagatag
     2161 ggttgagtgt tgttccagtt tggaacaaga gtccactatt aaagaacgtg gactccaacg
     2221 tcaaagggcg aaaaaccgtc tatcagggcg atggcccact acgtgaacca tcaccctaat
     2281 caagtttttt ggggtcgagg tgccgtaaag cactaaatcg gaaccctaaa gggagccccc
     2341 gatttagagc ttgacgggga aagccggcga acgtggcgag aaaggaaggg aagaaagcga
     2401 aaggagcggg cgctagggcg ctggcaagtg tagcggtcac gctgcgcgta accaccacac
     2461 ccgccgcgct taatgcgccg ctacagggcg cgtcaggtgg cacttttcgg ggaaatgtgc
     2521 gcggaacccc tatttgttta tttttctaaa tacattcaaa tatgtatccg ctcatgagac
     2581 aataaccctg ataaatgctt caataatatt gaaaaaggaa gagtcctgag gcggaaagaa
     2641 ccagctgtgg aatgtgtgtc agttagggtg tggaaagtcc ccaggctccc cagcaggcag
     2701 aagtatgcaa agcatgcatc tcaattagtc agcaaccagg tgtggaaagt ccccaggctc
     2761 cccagcaggc agaagtatgc aaagcatgca tctcaattag tcagcaacca tagtcccgcc
     2821 cctaactccg cccatcccgc ccctaactcc gcccagttcc gcccattctc cgccccatgg
     2881 ctgactaatt ttttttattt atgcagaggc cgaggccgcc tcggcctctg agctattcca
     2941 gaagtagtga ggaggctttt ttggaggcct aggcttttgc aaagatcgat caagagacag
     3001 gatgaggatc gtttcgcatg attgaacaag atggattgca cgcaggttct ccggccgctt
     3061 gggtggagag gctattcggc tatgactggg cacaacagac aatcggctgc tctgatgccg
     3121 ccgtgttccg gctgtcagcg caggggcgcc cggttctttt tgtcaagacc gacctgtccg
     3181 gtgccctgaa tgaactgcaa gacgaggcag cgcggctatc gtggctggcc acgacgggcg
     3241 ttccttgcgc agctgtgctc gacgttgtca ctgaagcggg aagggactgg ctgctattgg
     3301 gcgaagtgcc ggggcaggat ctcctgtcat ctcaccttgc tcctgccgag aaagtatcca
     3361 tcatggctga tgcaatgcgg cggctgcata cgcttgatcc ggctacctgc ccattcgacc
     3421 accaagcgaa acatcgcatc gagcgagcac gtactcggat ggaagccggt cttgtcgatc
     3481 aggatgatct ggacgaagag catcaggggc tcgcgccagc cgaactgttc gccaggctca
     3541 aggcgagcat gcccgacggc gaggatctcg tcgtgaccca tggcgatgcc tgcttgccga
     3601 atatcatggt ggaaaatggc cgcttttctg gattcatcga ctgtggccgg ctgggtgtgg
     3661 cggaccgcta tcaggacata gcgttggcta cccgtgatat tgctgaagag cttggcggcg
     3721 aatgggctga ccgcttcctc gtgctttacg gtatcgccgc tcccgattcg cagcgcatcg
     3781 ccttctatcg ccttcttgac gagttcttct gagcgggact ctggggttcg aaatgaccga
     3841 ccaagcgacg cccaacctgc catcacgaga tttcgattcc accgccgcct tctatgaaag
     3901 gttgggcttc ggaatcgttt tccgggacgc cggctggatg atcctccagc gcggggatct
     3961 catgctggag ttcttcgccc accctagggg gaggctaact gaaacacgga aggagacaat
     4021 accggaagga acccgcgcta tgacggcaat aaaaagacag aataaaacgc acggtgttgg
     4081 gtcgtttgtt cataaacgcg gggttcggtc ccagggctgg cactctgtcg ataccccacc
     4141 gagaccccat tggggccaat acgcccgcgt ttcttccttt tccccacccc accccccaag
     4201 ttcgggtgaa ggcccagggc tcgcagccaa cgtcggggcg gcaggccctg ccatagcctc
     4261 aggttactca tatatacttt agattgattt aaaacttcat ttttaattta aaaggatcta
     4321 ggtgaagatc ctttttgata atctcatgac caaaatccct taacgtgagt tttcgttcca
     4381 ctgagcgtca gaccccgtag aaaagatcaa aggatcttct tgagatcctt tttttctgcg
     4441 cgtaatctgc tgcttgcaaa caaaaaaacc accgctacca gcggtggttt gtttgccgga
     4501 tcaagagcta ccaactcttt ttccgaaggt aactggcttc agcagagcgc agataccaaa
     4561 tactgttctt ctagtgtagc cgtagttagg ccaccacttc aagaactctg tagcaccgcc
     4621 tacatacctc gctctgctaa tcctgttacc agtggctgct gccagtggcg ataagtcgtg
     4681 tcttaccggg ttggactcaa gacgatagtt accggataag gcgcagcggt cgggctgaac
     4741 ggggggttcg tgcacacagc ccagcttgga gcgaacgacc tacaccgaac tgagatacct
     4801 acagcgtgag ctatgagaaa gcgccacgct tcccgaaggg agaaaggcgg acaggtatcc
     4861 ggtaagcggc agggtcggaa caggagagcg cacgagggag cttccagggg gaaacgcctg
     4921 gtatctttat agtcctgtcg ggtttcgcca cctctgactt gagcgtcgat ttttgtgatg
     4981 ctcgtcaggg gggcggagcc tatggaaaaa cgccagcaac gcggcctttt tacggttcct
     5041 ggccttttgc tggccttttg ctcacatgtt ctttcctgcg ttatcccctg attctgtgga
     5101 taaccgtatt accgc
//
