pCytERM-miRFP2-N1

LOCUS       pCytERM-miRFP2-N1                5028 bp DNA     circular SYN 27-MAY-2024
DEFINITION  Vector for fusing EGFP to the C-terminus of a partner protein. For
            other reading frames, use pEGFP-N2 or pEGFP-N3.
ACCESSION   U55762
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 5028)
  AUTHORS   Clontech (TaKaRa)
  TITLE     Direct Submission
  JOURNAL   Exported Jun 24, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
FEATURES             Location/Qualifiers
     source          1..5028
                     /lab_host="Mammalian Cells"
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     enhancer        61..364
                     /label=CMV enhancer
                     /note="human cytomegalovirus immediate early enhancer"
     promoter        365..568
                     /label=CMV promoter
                     /note="human cytomegalovirus (CMV) immediate early
                     promoter"
     misc_feature    591..745
                     /label=MCS
                     /note="multiple cloning site of fluorescent protein
                     plasmids"
     CDS             615..701
                     /codon_start=1
                     /product="cytochrome P-450 IIC1, partial [Oryctolagus
                     cuniculus]
                     Sequence ID: AAA31436.1Length: 56Number of Matches: 1"
                     /label=cytochrome P-450
                     /translation="MDPVVVLGLCLSCLLLLSLWKQSYGGGKL"
     misc_feature    747..752
                     /label=Kozak
     CDS             753..1691
                     /codon_start=1
                     /label=miRFP2
                     /translation="MVAGHASGSPDFGTASPSDCEHEEIHLAGSIQPHGTLLVVSEPDH
                     RIIQASANAAEFLNLGSVLGIPLAEIDGDLLIKILPHLDLTAEGMPVAVRCRIGNPSTE
                     YDGLMHRPPEGGLIIELERAGPSIDLSGTLAPALERIRTAGSLRALCDDTVLLFQQCTG
                     YDRVMVYRFDERGHGEVYSEIHVTGLESYFGNRYPSSLVPQMARRLYVRQRVRVLVDVT
                     YQPVPLEPRLSPLTGRDLDMSGCFLRSMSPTHLQFLKNMGVRATLVVSLVVGGKLWGLV
                     ICHHYLPRFIHFELRAICVLLAEAIATRITAL"
     misc_feature    801..803
                     /label=Feature 3
     unsure          892
                     /label=Val
     unsure          1132..1133
                     /label=Ser
     unsure          1215..1217
                     /label=Val
     CDS             1353..1355
                     /label=Thr
     unsure          1383
                     /label=Val
     unsure          1417
                     /label=Thr
     CDS             1509..1511
                     /label=Cys
     unsure          1531
                     /label=Asp
     unsure          1554..1556
                     /label=Ala
     polyA_signal    1816..1937
                     /label=SV40 poly(A) signal
                     /note="SV40 polyadenylation signal"
     rep_origin      complement(1944..2399)
                     /direction=LEFT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     promoter        2426..2530
                     /gene="bla"
                     /label=AmpR promoter
     promoter        2532..2889
                     /label=SV40 promoter
                     /note="SV40 enhancer and early promoter"
     rep_origin      2740..2875
                     /label=SV40 ori
                     /note="SV40 origin of replication"
     CDS             2924..3718
                     /codon_start=1
                     /gene="aph(3')-II (or nptII)"
                     /product="aminoglycoside phosphotransferase from Tn5"
                     /label=NeoR/KanR
                     /note="confers resistance to neomycin, kanamycin, and G418
                     (Geneticin)"
                     /translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGRP
                     VLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDLLS
                     SHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDEEHQ
                     GLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRYQDIA
                     LATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF"
     misc_feature    3950..3997
                     /label=HSV TK poly(A) signal
                     /note="herpesvirus thymidine kinase polyadenylation signal"
     rep_origin      4326..4914
                     /direction=RIGHT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
ORIGIN
        1 tagttattaa tagtaatcaa ttacggggtc attagttcat agcccatata tggagttccg
       61 cgttacataa cttacggtaa atggcccgcc tggctgaccg cccaacgacc cccgcccatt
      121 gacgtcaata atgacgtatg ttcccatagt aacgccaata gggactttcc attgacgtca
      181 atgggtggag tatttacggt aaactgccca cttggcagta catcaagtgt atcatatgcc
      241 aagtacgccc cctattgacg tcaatgacgg taaatggccc gcctggcatt atgcccagta
      301 catgacctta tgggactttc ctacttggca gtacatctac gtattagtca tcgctattac
      361 catggtgatg cggttttggc agtacatcaa tgggcgtgga tagcggtttg actcacgggg
      421 atttccaagt ctccacccca ttgacgtcaa tgggagtttg ttttggcacc aaaatcaacg
      481 ggactttcca aaatgtcgta acaactccgc cccattgacg caaatgggcg gtaggcgtgt
      541 acggtgggag gtctatataa gcagagctgg tttagtgaac cgtcagatcc gctagcgcta
      601 ccggactcag atctatggac cctgtggtgg tgctggggct ctgtctctcc tgtttgcttc
      661 tcctttcact ctggaaacag agctatgggg gagggaagct tcgaattctg cagtcgacgg
      721 taccgcgggc ccgggatcca ccggtcgcca ccatggtcgc aggacacgca agtggaagcc
      781 ccgactttgg aaccgccagt ccgagcgact gtgagcacga agaaatccat ctggccggat
      841 ccatccagcc acacggaaca ctgctggtgg tctccgagcc tgaccataga ataattcagg
      901 catctgccaa cgccgctgaa ttcctgaatc tgggaagtgt gctgggaatc cccctggctg
      961 agatcgacgg ggatctactg atcaagattc tgccccacct ggaccttacc gcagaaggaa
     1021 tgccagtggc cgtcaggtgc cgcattggaa acccctccac agagtacgac ggactgatgc
     1081 atcgaccacc tgaaggagga ctgatcattg agctggaacg ggctgggcca tccattgatc
     1141 tgagcggaac actggctccc gcactggagc gaattcgaac tgcaggatcc ctgagggctc
     1201 tgtgcgacga tactgtactg ctgttccagc agtgtaccgg ctacgaccga gtgatggtct
     1261 atcggttcga tgaacggggg cacggagagg tgtattcaga aattcatgtg actggactgg
     1321 agagctactt tggcaacagg tatcctagct ccctcgtgcc acagatggcc cggcggctgt
     1381 acgtgagaca gagggtgcgc gtcctggtag atgtcaccta tcagcctgtg ccactggagc
     1441 caagactgag tcccctgact ggcagggacc tggatatgtc agggtgtttt ctgcgctcta
     1501 tgagtcctac tcacctgcag ttcctgaaga acatgggcgt gcgggcaaca ctggtggtca
     1561 gcctggtggt cggaggcaaa ctgtgggggc tggtgatctg ccaccattat ctgccacgct
     1621 tcatccattt tgagctgcga gcaatttgtg tgctgctggc cgaagctatc gcaacccgca
     1681 ttacagccct gtaagcggcc gcgactctag atcataatca gccataccac atttgtagag
     1741 gttttacttg ctttaaaaaa cctcccacac ctccccctga acctgaaaca taaaatgaat
     1801 gcaattgttg ttgttaactt gtttattgca gcttataatg gttacaaata aagcaatagc
     1861 atcacaaatt tcacaaataa agcatttttt tcactgcatt ctagttgtgg tttgtccaaa
     1921 ctcatcaatg tatcttaagg cgtaaattgt aagcgttaat attttgttaa aattcgcgtt
     1981 aaatttttgt taaatcagct cattttttaa ccaataggcc gaaatcggca aaatccctta
     2041 taaatcaaaa gaatagaccg agatagggtt gagtgttgtt ccagtttgga acaagagtcc
     2101 actattaaag aacgtggact ccaacgtcaa agggcgaaaa accgtctatc agggcgatgg
     2161 cccactacgt gaaccatcac cctaatcaag ttttttgggg tcgaggtgcc gtaaagcact
     2221 aaatcggaac cctaaaggga gcccccgatt tagagcttga cggggaaagc cggcgaacgt
     2281 ggcgagaaag gaagggaaga aagcgaaagg agcgggcgct agggcgctgg caagtgtagc
     2341 ggtcacgctg cgcgtaacca ccacacccgc cgcgcttaat gcgccgctac agggcgcgtc
     2401 aggtggcact tttcggggaa atgtgcgcgg aacccctatt tgtttatttt tctaaataca
     2461 ttcaaatatg tatccgctca tgagacaata accctgataa atgcttcaat aatattgaaa
     2521 aaggaagagt cctgaggcgg aaagaaccag ctgtggaatg tgtgtcagtt agggtgtgga
     2581 aagtccccag gctccccagc aggcagaagt atgcaaagca tgcatctcaa ttagtcagca
     2641 accaggtgtg gaaagtcccc aggctcccca gcaggcagaa gtatgcaaag catgcatctc
     2701 aattagtcag caaccatagt cccgccccta actccgccca tcccgcccct aactccgccc
     2761 agttccgccc attctccgcc ccatggctga ctaatttttt ttatttatgc agaggccgag
     2821 gccgcctcgg cctctgagct attccagaag tagtgaggag gcttttttgg aggcctaggc
     2881 ttttgcaaag atcgatcaag agacaggatg aggatcgttt cgcatgattg aacaagatgg
     2941 attgcacgca ggttctccgg ccgcttgggt ggagaggcta ttcggctatg actgggcaca
     3001 acagacaatc ggctgctctg atgccgccgt gttccggctg tcagcgcagg ggcgcccggt
     3061 tctttttgtc aagaccgacc tgtccggtgc cctgaatgaa ctgcaagacg aggcagcgcg
     3121 gctatcgtgg ctggccacga cgggcgttcc ttgcgcagct gtgctcgacg ttgtcactga
     3181 agcgggaagg gactggctgc tattgggcga agtgccgggg caggatctcc tgtcatctca
     3241 ccttgctcct gccgagaaag tatccatcat ggctgatgca atgcggcggc tgcatacgct
     3301 tgatccggct acctgcccat tcgaccacca agcgaaacat cgcatcgagc gagcacgtac
     3361 tcggatggaa gccggtcttg tcgatcagga tgatctggac gaagagcatc aggggctcgc
     3421 gccagccgaa ctgttcgcca ggctcaaggc gagcatgccc gacggcgagg atctcgtcgt
     3481 gacccatggc gatgcctgct tgccgaatat catggtggaa aatggccgct tttctggatt
     3541 catcgactgt ggccggctgg gtgtggcgga ccgctatcag gacatagcgt tggctacccg
     3601 tgatattgct gaagagcttg gcggcgaatg ggctgaccgc ttcctcgtgc tttacggtat
     3661 cgccgctccc gattcgcagc gcatcgcctt ctatcgcctt cttgacgagt tcttctgagc
     3721 gggactctgg ggttcgaaat gaccgaccaa gcgacgccca acctgccatc acgagatttc
     3781 gattccaccg ccgccttcta tgaaaggttg ggcttcggaa tcgttttccg ggacgccggc
     3841 tggatgatcc tccagcgcgg ggatctcatg ctggagttct tcgcccaccc tagggggagg
     3901 ctaactgaaa cacggaagga gacaataccg gaaggaaccc gcgctatgac ggcaataaaa
     3961 agacagaata aaacgcacgg tgttgggtcg tttgttcata aacgcggggt tcggtcccag
     4021 ggctggcact ctgtcgatac cccaccgaga ccccattggg gccaatacgc ccgcgtttct
     4081 tccttttccc caccccaccc cccaagttcg ggtgaaggcc cagggctcgc agccaacgtc
     4141 ggggcggcag gccctgccat agcctcaggt tactcatata tactttagat tgatttaaaa
     4201 cttcattttt aatttaaaag gatctaggtg aagatccttt ttgataatct catgaccaaa
     4261 atcccttaac gtgagttttc gttccactga gcgtcagacc ccgtagaaaa gatcaaagga
     4321 tcttcttgag atcctttttt tctgcgcgta atctgctgct tgcaaacaaa aaaaccaccg
     4381 ctaccagcgg tggtttgttt gccggatcaa gagctaccaa ctctttttcc gaaggtaact
     4441 ggcttcagca gagcgcagat accaaatact gtccttctag tgtagccgta gttaggccac
     4501 cacttcaaga actctgtagc accgcctaca tacctcgctc tgctaatcct gttaccagtg
     4561 gctgctgcca gtggcgataa gtcgtgtctt accgggttgg actcaagacg atagttaccg
     4621 gataaggcgc agcggtcggg ctgaacgggg ggttcgtgca cacagcccag cttggagcga
     4681 acgacctaca ccgaactgag atacctacag cgtgagctat gagaaagcgc cacgcttccc
     4741 gaagggagaa aggcggacag gtatccggta agcggcaggg tcggaacagg agagcgcacg
     4801 agggagcttc cagggggaaa cgcctggtat ctttatagtc ctgtcgggtt tcgccacctc
     4861 tgacttgagc gtcgattttt gtgatgctcg tcaggggggc ggagcctatg gaaaaacgcc
     4921 agcaacgcgg cctttttacg gttcctggcc ttttgctggc cttttgctca catgttcttt
     4981 cctgcgttat cccctgattc tgtggataac cgtattaccg ccatgcat
//
