pCytERM-mCardinal-N1

LOCUS       pCytERM-mCardinal-N1                4821 bp DNA     circular SYN 27-MAY-2024
DEFINITION  Vector for fusing EGFP to the C-terminus of a partner protein. For
            other reading frames, use pEGFP-N2 or pEGFP-N3.
ACCESSION   U55762
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 4821)
  AUTHORS   Clontech (TaKaRa)
  TITLE     Direct Submission
  JOURNAL   Exported Jun 23, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
FEATURES             Location/Qualifiers
     source          1..4821
                     /lab_host="Mammalian Cells"
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     enhancer        61..364
                     /label=CMV enhancer
                     /note="human cytomegalovirus immediate early enhancer"
     promoter        365..568
                     /label=CMV promoter
                     /note="human cytomegalovirus (CMV) immediate early
                     promoter"
     CDS             615..701
                     /codon_start=1
                     /product="cytochrome P-450 IIC1, partial [Oryctolagus
                     cuniculus]
                     Sequence ID: AAA31436.1Length: 56Number of Matches: 1"
                     /label=cytochrome P-450
                     /translation="MDPVVVLGLCLSCLLLLSLWKQSYGGGKL"
     primer_bind     725..772
                     /label=0222-366-F
     misc_feature    747..752
                     /label=Kozak
     CDS             753..1484
                     /codon_start=1
                     /product="far-red fluorescent protein derived from
                     mNeptune, with further red-shifted spectra"
                     /label=mCardinal
                     /translation="MVSKGEELIKENMHMKLYMEGTVNNHHFKCTTEGEGKPYEGTQTQ
                     RIKVVEGGPLPFAFDILATCFMYGSKTFINHTQGIPDFFKQSFPEGFTWERVTTYEDGG
                     VLTVTQDTSLQDGCLIYNVKLRGVNFPSNGPVMQKKTLGWEATTETLYPADGGLEGRCD
                     MALKLVGGGHLHCNLKTTYRSKKPAKNLKMPGVYFVDRRLERIKEADNETYVEQHEVAV
                     ARYCDLPSKLGHKLNGMDELYK"
     regulatory      753..756
                     /label=Kozak sequence
                     /note="vertebrate consensus sequence for strong initiation
                     of translation (Kozak, 1987)"
                     /regulatory_class="other"
     primer_bind     complement(1463..1510)
                     /label=0222-366-R
     polyA_signal    1609..1730
                     /label=SV40 poly(A) signal
                     /note="SV40 polyadenylation signal"
     rep_origin      complement(1737..2192)
                     /direction=LEFT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     promoter        2219..2323
                     /gene="bla"
                     /label=AmpR promoter
     promoter        2325..2682
                     /label=SV40 promoter
                     /note="SV40 enhancer and early promoter"
     rep_origin      2533..2668
                     /label=SV40 ori
                     /note="SV40 origin of replication"
     CDS             2717..3511
                     /codon_start=1
                     /gene="aph(3')-II (or nptII)"
                     /product="aminoglycoside phosphotransferase from Tn5"
                     /label=NeoR/KanR
                     /note="confers resistance to neomycin, kanamycin, and G418
                     (Geneticin)"
                     /translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGRP
                     VLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDLLS
                     SHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDEEHQ
                     GLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRYQDIA
                     LATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF"
     misc_feature    3743..3790
                     /label=HSV TK poly(A) signal
                     /note="herpesvirus thymidine kinase polyadenylation signal"
     rep_origin      4119..4707
                     /direction=RIGHT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
ORIGIN
        1 tagttattaa tagtaatcaa ttacggggtc attagttcat agcccatata tggagttccg
       61 cgttacataa cttacggtaa atggcccgcc tggctgaccg cccaacgacc cccgcccatt
      121 gacgtcaata atgacgtatg ttcccatagt aacgccaata gggactttcc attgacgtca
      181 atgggtggag tatttacggt aaactgccca cttggcagta catcaagtgt atcatatgcc
      241 aagtacgccc cctattgacg tcaatgacgg taaatggccc gcctggcatt atgcccagta
      301 catgacctta tgggactttc ctacttggca gtacatctac gtattagtca tcgctattac
      361 catggtgatg cggttttggc agtacatcaa tgggcgtgga tagcggtttg actcacgggg
      421 atttccaagt ctccacccca ttgacgtcaa tgggagtttg ttttggcacc aaaatcaacg
      481 ggactttcca aaatgtcgta acaactccgc cccattgacg caaatgggcg gtaggcgtgt
      541 acggtgggag gtctatataa gcagagctgg tttagtgaac cgtcagatcc gctagcgcta
      601 ccggactcag atctatggac cctgtggtgg tgctggggct ctgtctctcc tgtttgcttc
      661 tcctttcact ctggaaacag agctatgggg gagggaagct tcgaattctg cagtcgacgg
      721 taccgcgggc ccgggatcca ccggtcgcca ccatggtgag caagggcgag gagctgatca
      781 aggagaacat gcacatgaag ctgtacatgg aaggcaccgt gaacaaccac cacttcaagt
      841 gcaccaccga aggggagggc aagccctacg agggcaccca gacccagagg attaaggtgg
      901 tggagggagg ccccctgccg ttcgcattcg acatcctggc cacctgcttt atgtacggga
      961 gcaagacctt catcaaccac acccagggca tccccgattt ctttaagcag tccttccctg
     1021 agggcttcac atgggagaga gtcaccacat acgaagacgg gggcgtgctt accgttaccc
     1081 aggacaccag cctccaggac ggctgcttga tctacaacgt caagctcaga ggggtgaact
     1141 tcccatccaa cggccctgtg atgcagaaga aaacactcgg ctgggaggcc accaccgaga
     1201 ccctgtaccc cgctgacggc ggcctggaag gcagatgcga catggccctg aagctcgtgg
     1261 gcgggggcca cctgcactgc aacctgaaga ccacatacag atccaagaaa cccgctaaga
     1321 acctcaagat gcccggcgtc tactttgtgg accgcagact ggaaagaatc aaggaggccg
     1381 acaatgagac ctacgtcgag cagcacgagg tggctgtggc cagatactgc gacctcccta
     1441 gcaaactggg gcacaaactt aatggcatgg acgagctgta caagtaagcg gccgcgactc
     1501 tagatcataa tcagccatac cacatttgta gaggttttac ttgctttaaa aaacctccca
     1561 cacctccccc tgaacctgaa acataaaatg aatgcaattg ttgttgttaa cttgtttatt
     1621 gcagcttata atggttacaa ataaagcaat agcatcacaa atttcacaaa taaagcattt
     1681 ttttcactgc attctagttg tggtttgtcc aaactcatca atgtatctta aggcgtaaat
     1741 tgtaagcgtt aatattttgt taaaattcgc gttaaatttt tgttaaatca gctcattttt
     1801 taaccaatag gccgaaatcg gcaaaatccc ttataaatca aaagaataga ccgagatagg
     1861 gttgagtgtt gttccagttt ggaacaagag tccactatta aagaacgtgg actccaacgt
     1921 caaagggcga aaaaccgtct atcagggcga tggcccacta cgtgaaccat caccctaatc
     1981 aagttttttg gggtcgaggt gccgtaaagc actaaatcgg aaccctaaag ggagcccccg
     2041 atttagagct tgacggggaa agccggcgaa cgtggcgaga aaggaaggga agaaagcgaa
     2101 aggagcgggc gctagggcgc tggcaagtgt agcggtcacg ctgcgcgtaa ccaccacacc
     2161 cgccgcgctt aatgcgccgc tacagggcgc gtcaggtggc acttttcggg gaaatgtgcg
     2221 cggaacccct atttgtttat ttttctaaat acattcaaat atgtatccgc tcatgagaca
     2281 ataaccctga taaatgcttc aataatattg aaaaaggaag agtcctgagg cggaaagaac
     2341 cagctgtgga atgtgtgtca gttagggtgt ggaaagtccc caggctcccc agcaggcaga
     2401 agtatgcaaa gcatgcatct caattagtca gcaaccaggt gtggaaagtc cccaggctcc
     2461 ccagcaggca gaagtatgca aagcatgcat ctcaattagt cagcaaccat agtcccgccc
     2521 ctaactccgc ccatcccgcc cctaactccg cccagttccg cccattctcc gccccatggc
     2581 tgactaattt tttttattta tgcagaggcc gaggccgcct cggcctctga gctattccag
     2641 aagtagtgag gaggcttttt tggaggccta ggcttttgca aagatcgatc aagagacagg
     2701 atgaggatcg tttcgcatga ttgaacaaga tggattgcac gcaggttctc cggccgcttg
     2761 ggtggagagg ctattcggct atgactgggc acaacagaca atcggctgct ctgatgccgc
     2821 cgtgttccgg ctgtcagcgc aggggcgccc ggttcttttt gtcaagaccg acctgtccgg
     2881 tgccctgaat gaactgcaag acgaggcagc gcggctatcg tggctggcca cgacgggcgt
     2941 tccttgcgca gctgtgctcg acgttgtcac tgaagcggga agggactggc tgctattggg
     3001 cgaagtgccg gggcaggatc tcctgtcatc tcaccttgct cctgccgaga aagtatccat
     3061 catggctgat gcaatgcggc ggctgcatac gcttgatccg gctacctgcc cattcgacca
     3121 ccaagcgaaa catcgcatcg agcgagcacg tactcggatg gaagccggtc ttgtcgatca
     3181 ggatgatctg gacgaagagc atcaggggct cgcgccagcc gaactgttcg ccaggctcaa
     3241 ggcgagcatg cccgacggcg aggatctcgt cgtgacccat ggcgatgcct gcttgccgaa
     3301 tatcatggtg gaaaatggcc gcttttctgg attcatcgac tgtggccggc tgggtgtggc
     3361 ggaccgctat caggacatag cgttggctac ccgtgatatt gctgaagagc ttggcggcga
     3421 atgggctgac cgcttcctcg tgctttacgg tatcgccgct cccgattcgc agcgcatcgc
     3481 cttctatcgc cttcttgacg agttcttctg agcgggactc tggggttcga aatgaccgac
     3541 caagcgacgc ccaacctgcc atcacgagat ttcgattcca ccgccgcctt ctatgaaagg
     3601 ttgggcttcg gaatcgtttt ccgggacgcc ggctggatga tcctccagcg cggggatctc
     3661 atgctggagt tcttcgccca ccctaggggg aggctaactg aaacacggaa ggagacaata
     3721 ccggaaggaa cccgcgctat gacggcaata aaaagacaga ataaaacgca cggtgttggg
     3781 tcgtttgttc ataaacgcgg ggttcggtcc cagggctggc actctgtcga taccccaccg
     3841 agaccccatt ggggccaata cgcccgcgtt tcttcctttt ccccacccca ccccccaagt
     3901 tcgggtgaag gcccagggct cgcagccaac gtcggggcgg caggccctgc catagcctca
     3961 ggttactcat atatacttta gattgattta aaacttcatt tttaatttaa aaggatctag
     4021 gtgaagatcc tttttgataa tctcatgacc aaaatccctt aacgtgagtt ttcgttccac
     4081 tgagcgtcag accccgtaga aaagatcaaa ggatcttctt gagatccttt ttttctgcgc
     4141 gtaatctgct gcttgcaaac aaaaaaacca ccgctaccag cggtggtttg tttgccggat
     4201 caagagctac caactctttt tccgaaggta actggcttca gcagagcgca gataccaaat
     4261 actgtccttc tagtgtagcc gtagttaggc caccacttca agaactctgt agcaccgcct
     4321 acatacctcg ctctgctaat cctgttacca gtggctgctg ccagtggcga taagtcgtgt
     4381 cttaccgggt tggactcaag acgatagtta ccggataagg cgcagcggtc gggctgaacg
     4441 gggggttcgt gcacacagcc cagcttggag cgaacgacct acaccgaact gagataccta
     4501 cagcgtgagc tatgagaaag cgccacgctt cccgaaggga gaaaggcgga caggtatccg
     4561 gtaagcggca gggtcggaac aggagagcgc acgagggagc ttccaggggg aaacgcctgg
     4621 tatctttata gtcctgtcgg gtttcgccac ctctgacttg agcgtcgatt tttgtgatgc
     4681 tcgtcagggg ggcggagcct atggaaaaac gccagcaacg cggccttttt acggttcctg
     4741 gccttttgct ggccttttgc tcacatgttc tttcctgcgt tatcccctga ttctgtggat
     4801 aaccgtatta ccgccatgca t
//
