pStayGold-Tubulin

LOCUS       pStayGold-Tubulin              7448 bp DNA     circular SYN 01-NOV-2023
DEFINITION  Human alpha-tubulin labeling with near-infrared fluorescent protein
            miRFP670nano.
ACCESSION   .
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 7448)
  AUTHORS   Oliinyk OS, Shemetov AA, Pletnev S, Shcherbakova DM, Verkhusha VV
  TITLE     Smallest near-infrared fluorescent protein evolved from
            cyanobacteriochrome as versatile tag for spectral multiplexing.
  JOURNAL   Nat Commun. 2019 Jan 17;10(1):279. doi: 10.1038/s41467-018-08050-8.
  PUBMED    30655515
REFERENCE   2  (bases 1 to 7448)
  AUTHORS   .
  TITLE     Direct Submission
  JOURNAL   Exported Jul 2, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
COMMENT     SGRef: number: 1; type: "Journal Article"; journalName: "Nat
            Commun."; date: "2019-01-17"; volume: "10(1):279. doi"; pages: "
            10.1038/s41467-018-08050-8"
FEATURES             Location/Qualifiers
     source          1..7448
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     enhancer        137..516
                     /label=CMV enhancer
                     /note="human cytomegalovirus immediate early enhancer"
     promoter        517..720
                     /label=CMV promoter
                     /note="human cytomegalovirus (CMV) immediate early
                     promoter"
     primer_bind     671..691
                     /label=CMV-F
                     /note="Human CMV immediate early promoter, forward primer"
     primer_bind     765..784
                     /label=T7
                     /note="T7 promoter, forward primer"
     promoter        765..783
                     /label=T7 promoter
                     /note="promoter for bacteriophage T7 RNA polymerase"
     regulatory      803..808
                     /label=Kozak sequence
                     /note="vertebrate consensus sequence for strong initiation
                     of translation (Kozak, 1987)"
                     /regulatory_class="other"
     CDS             809..1459
                     /codon_start=1
                     /label=StayGold
                     /translation="MASTPFKFQLKGTINGKSFTVEGEGEGNSHEGSHKGKYVCTSGKL
                     PMSWAALGTSFGYGMKYYTKYPSGLKNWFHEVMPEGFTYDRHIQYKGDGSIHAKHQHFM
                     KNGTYHNIVEFTGQDFKENSPVLTGDMNVSLPNEVQHIPRDDGVECPVTLLYPLLSDKS
                     KCVEAHQNTICKPLHNQPAPDVPYHWIRKQYTQSKDDTEERDHICQSETLEAHL"
     primer_bind     1462..1520
                     /label=0708-2-Tubulin-F
     CDS             1520..2875
                     /codon_start=1
                     /label=TUBA1B
                     /translation="VRECISIHVGQAGVQIGNACWELYCLEHGIQPDGQMPSDKTIGGG
                     DDSFNTFFSETGAGKHVPRAVFVDLEPTVIDEVRTGTYRQLFHPEQLITGKEDAANNYA
                     RGHYTIGKEIIDLVLDRIRKLADQCTGLQGFLVFHSFGGGTGSGFTSLLMERLSVDYGK
                     KSKLEFSIYPAPQVSTAVVEPYNSILTTHTTLEHSDCAFMVDNEAIYDICRRNLDIERP
                     TYTNLNRLISQIVSSITASLRFDGALNVDLTEFQTNLVPYPRIHFPLATYAPVISAEKA
                     YHEQLSVAEITNACFEPANQMVKCDPRHGKYMACCLLYRGDVVPKDVNAAIATIKTKRS
                     IQFVDWCPTGFKVGINYQPPTVVPGGDLAKVQRAVCMLSNTTAIAEAWARLDHKFDLMY
                     AKRAFVHWYVGEGMEEGEFSEAREDMAALEKDYEEVGVDSVEGEGEEEGEEY"
     primer_bind     1520..1540
                     /label=Tubulin-F
     primer_bind     complement(1709..1730)
                     /label=Tubulin-R
     promoter        complement(2903..2921)
                     /label=SP6 promoter
                     /note="promoter for bacteriophage SP6 RNA polymerase"
     primer_bind     complement(2941..2963)
                     /label=bGH-polyA-R
     polyA_signal    2947..3171
                     /label=bGH poly(A) signal
                     /note="bovine growth hormone polyadenylation signal"
     rep_origin      3217..3645
                     /direction=RIGHT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     primer_bind     complement(3304..3323)
                     /label=F1ori-R
                     /note="F1 origin, reverse primer"
     primer_bind     3514..3535
                     /label=F1ori-F
                     /note="F1 origin, forward primer"
     primer_bind     complement(3654..3674)
                     /label=pBABE 3'
                     /note="SV40 enhancer, reverse primer for pBABE vectors"
     promoter        3659..3988
                     /label=SV40 promoter
                     /note="SV40 enhancer and early promoter"
     rep_origin      3839..3974
                     /label=SV40 ori
                     /note="SV40 origin of replication"
     primer_bind     3901..3920
                     /label=SV40pro-F
                     /note="SV40 promoter/origin, forward primer"
     CDS             4055..4849
                     /codon_start=1
                     /gene="aph(3')-II (or nptII)"
                     /product="aminoglycoside phosphotransferase from Tn5"
                     /label=NeoR/KanR
                     /note="confers resistance to neomycin, kanamycin, and G418
                     (Geneticin(R))"
                     /translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGRP
                     VLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDLLS
                     SHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDEEHQ
                     GLAPAELFARLKARMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRYQDIA
                     LATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF"
     primer_bind     complement(4109..4128)
                     /label=Neo-R
                     /note="Neomycin resistance gene, reverse primer"
     primer_bind     4719..4738
                     /label=Neo-F
                     /note="Neomycin resistance gene, forward primer"
     polyA_signal    5023..5144
                     /label=SV40 poly(A) signal
                     /note="SV40 polyadenylation signal"
     primer_bind     complement(5060..5079)
                     /label=SV40pA-R
                     /note="SV40 polyA, reverse primer"
     primer_bind     5114..5133
                     /label=EBV-rev
                     /note="SV40 polyA terminator, reverse primer"
     primer_bind     complement(5114..5133)
                     /label=SV40-R-Universal
     primer_bind     complement(5193..5209)
                     /label=M13 rev
                     /note="common sequencing primer, one of multiple similar
                     variants"
     primer_bind     complement(5193..5209)
                     /label=M13 Reverse
                     /note="In lacZ gene. Also called M13-rev"
     primer_bind     complement(5206..5228)
                     /label=M13/pUC Reverse
                     /note="In lacZ gene"
     protein_bind    5217..5233
                     /label=lac operator
                     /bound_moiety="lac repressor encoded by lacI"
                     /note="The lac repressor binds to the lac operator to
                     inhibit transcription in E. coli. This inhibition can be
                     relieved by adding lactose or
                     isopropyl-beta-D-thiogalactopyranoside (IPTG)."
     promoter        complement(5241..5271)
                     /label=lac promoter
                     /note="promoter for the E. coli lac operon"
     protein_bind    5286..5307
                     /label=CAP binding site
                     /bound_moiety="E. coli catabolite activator protein"
                     /note="CAP binding activates transcription in the presence
                     of cAMP."
     primer_bind     complement(5424..5441)
                     /label=L4440
                     /note="L4440 vector, forward primer"
     rep_origin      complement(5595..6183)
                     /direction=LEFT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
     primer_bind     complement(5675..5694)
                     /label=pBR322ori-F
                     /note="pBR322 origin, forward primer"
     CDS             complement(6354..7214)
                     /codon_start=1
                     /gene="bla"
                     /product="beta-lactamase"
                     /label=AmpR
                     /note="confers resistance to ampicillin, carbenicillin, and
                     related antibiotics"
                     /translation="MSIQHFRVALIPFFAAFCLPVFAHPETLVKVKDAEDQLGARVGYI
                     ELDLNSGKILESFRPEERFPMMSTFKVLLCGAVLSRIDAGQEQLGRRIHYSQNDLVEYS
                     PVTEKHLTDGMTVRELCSAAITMSDNTAANLLLTTIGGPKELTAFLHNMGDHVTRLDRW
                     EPELNEAIPNDERDTTMPVAMATTLRKLLTGELLTLASRQQLIDWMEADKVAGPLLRSA
                     LPAGWFIADKSGAGERGSRGIIAALGPDGKPSRIVVIYTTGSQATMDERNRQIAEIGAS
                     LIKHW"
     primer_bind     6977..6996
                     /label=Amp-R
                     /note="Ampicillin resistance gene, reverse primer"
     promoter        complement(7215..7319)
                     /gene="bla"
                     /label=AmpR promoter
     primer_bind     complement(7394..7413)
                     /label=pRS-marker
                     /note="pRS vectors, use to sequence yeast selectable
                     marker"
ORIGIN
        1 ttggaggtcg ctgagtagtg cgcgagcaaa atttaagcta caacaaggca aggcttgacc
       61 gacaattgca tgaagaatct gcttagggtt aggcgttttg cgctgcttcg cgatgtacgg
      121 gccagatata cgcgttgaca ttgattattg actagttatt aatagtaatc aattacgggg
      181 tcattagttc atagcccata tatggagttc cgcgttacat aacttacggt aaatggcccg
      241 cctggctgac cgcccaacga cccccgccca ttgacgtcaa taatgacgta tgttcccata
      301 gtaacgccaa tagggacttt ccattgacgt caatgggtgg agtatttacg gtaaactgcc
      361 cacttggcag tacatcaagt gtatcatatg ccaagtacgc cccctattga cgtcaatgac
      421 ggtaaatggc ccgcctggca ttatgcccag tacatgacct tatgggactt tcctacttgg
      481 cagtacatct acgtattagt catcgctatt accatggtga tgcggttttg gcagtacatc
      541 aatgggcgtg gatagcggtt tgactcacgg ggatttccaa gtctccaccc cattgacgtc
      601 aatgggagtt tgttttggca ccaaaatcaa cgggactttc caaaatgtcg taacaactcc
      661 gccccattga cgcaaatggg cggtaggcgt gtacggtggg aggtctatat aagcagagct
      721 ctctggctaa ctagagaacc cactgcttac tggcttatcg aaattaatac gactcactat
      781 agggagaccc aagcttggta ccgccaccat ggctagtaca ccatttaaat ttcaacttaa
      841 aggaaccatc aatggcaaat cgtttaccgt tgaaggcgaa ggtgaaggaa attcacatga
      901 aggttctcat aaaggaaaat atgtttgtac aagtggaaaa ctaccgatgt catgggcagc
      961 acttggaaca tcctttggtt atggaatgaa atattatacc aaatatccta gtggactgaa
     1021 gaactggttt catgaagtaa tgcctgaagg ctttacctac gatcgtcata ttcaatataa
     1081 aggcgatggg agtatccatg caaaacacca acactttatg aaaaatggga cttatcacaa
     1141 cattgttgaa tttactggtc aggattttaa agaaaatagt ccagtcttaa ctggagatat
     1201 gaatgtctca ttaccgaatg aagttcaaca tatacccaga gatgatggag tagaatgccc
     1261 agtgaccttg ctttatcctt tattatcgga taaatcaaaa tgcgttgagg ctcaccaaaa
     1321 tacaatctgc aagcctcttc ataatcaacc agcacctgat gtcccatatc actggattcg
     1381 taaacaatac acacaaagca aagatgatac cgaggaacgt gatcatattt gtcaatcaga
     1441 gactctcgaa gcacacttag gaggtggtgg atcaggagga ggtggttctg gaggtggtgg
     1501 atcaggagga agatctcgag tgcgtgagtg catctccatc cacgttggcc aggctggtgt
     1561 ccagattggc aatgcctgct gggagctcta ctgcctggaa cacggcatcc agcccgatgg
     1621 ccagatgcca agtgacaaga ccattggggg aggagatgac tccttcaaca ccttcttcag
     1681 tgagacgggc gctggcaagc acgtgccccg ggctgtgttt gtagacttgg aacccacagt
     1741 cattgatgaa gttcgcactg gcacctaccg ccagctcttc caccctgagc agctcatcac
     1801 aggcaaggaa gatgctgcca ataactatgc ccgagggcac tacaccattg gcaaggagat
     1861 cattgacctt gtgttggacc gaattcgcaa gctggctgac cagtgcaccg gtcttcaggg
     1921 cttcttggtt ttccacagct ttggtggggg aactggttct gggttcacct ccctgctcat
     1981 ggaacgtctc tcagttgatt atggcaagaa gtccaagctg gagttctcca tttacccagc
     2041 accccaggtt tccacagctg tagttgagcc ctacaactcc atcctcacca cccacaccac
     2101 cctggagcac tctgattgtg ccttcatggt agacaatgag gccatctatg acatctgtcg
     2161 tagaaacctc gatatcgagc gcccaaccta cactaacctt aaccgcctta ttagccagat
     2221 tgtgtcctcc atcactgctt ccctgagatt tgatggagcc ctgaatgttg acctgacaga
     2281 attccagacc aacctggtgc cctacccccg catccacttc cctctggcca catatgcccc
     2341 tgtcatctct gctgagaaag cctaccatga acagctttct gtagcagaga tcaccaatgc
     2401 ttgctttgag ccagccaacc agatggtgaa atgtgaccct cgccatggta aatacatggc
     2461 ttgctgcctg ttgtaccgtg gtgacgtggt tcccaaagat gtcaatgctg ccattgccac
     2521 catcaaaacc aagcgcagca tccagtttgt ggattggtgc cccactggct tcaaggttgg
     2581 catcaactac cagcctccca ctgtggtgcc tggtggagac ctggccaagg tacagagagc
     2641 tgtgtgcatg ctgagcaaca ccacagccat tgctgaggcc tgggctcgcc tggaccacaa
     2701 gtttgacctg atgtatgcca agcgtgcctt tgttcactgg tacgtgggtg aggggatgga
     2761 ggaaggcgag ttttcagagg cccgtgaaga tatggctgcc cttgagaagg attatgagga
     2821 ggttggtgtg gattctgttg aaggagaggg tgaggaagaa ggagaggaat actaaggatc
     2881 caccggatct agagggccct attctatagt gtcacctaaa tgctagagct cgctgatcag
     2941 cctcgactgt gccttctagt tgccagccat ctgttgtttg cccctccccc gtgccttcct
     3001 tgaccctgga aggtgccact cccactgtcc tttcctaata aaatgaggaa attgcatcgc
     3061 attgtctgag taggtgtcat tctattctgg ggggtggggt ggggcaggac agcaaggggg
     3121 aggattggga agacaatagc aggcatgctg gggatgcggt gggctctatg gcttctgagg
     3181 cggaaagaac cagctggggc tctagggggt atccccacgc gccctgtagc ggcgcattaa
     3241 gcgcggcggg tgtggtggtt acgcgcagcg tgaccgctac acttgccagc gccctagcgc
     3301 ccgctccttt cgctttcttc ccttcctttc tcgccacgtt cgccggcttt ccccgtcaag
     3361 ctctaaatcg ggggctccct ttagggttcc gatttagtgc tttacggcac ctcgacccca
     3421 aaaaacttga ttagggtgat ggttcacgta gtgggccatc gccctgatag acggtttttc
     3481 gccctttgac gttggagtcc acgttcttta atagtggact cttgttccaa actggaacaa
     3541 cactcaaccc tatctcggtc tattcttttg atttataagg gattttgccg atttcggcct
     3601 attggttaaa aaatgagctg atttaacaaa aatttaacgc gaattaattc tgtggaatgt
     3661 gtgtcagtta gggtgtggaa agtccccagg ctccccagca ggcagaagta tgcaaagcat
     3721 gcatctcaat tagtcagcaa ccaggtgtgg aaagtcccca ggctccccag caggcagaag
     3781 tatgcaaagc atgcatctca attagtcagc aaccatagtc ccgcccctaa ctccgcccat
     3841 cccgccccta actccgccca gttccgccca ttctccgccc catggctgac taattttttt
     3901 tatttatgca gaggccgagg ccgcctctgc ctctgagcta ttccagaagt agtgaggagg
     3961 cttttttgga ggcctaggct tttgcaaaaa gctcccggga gcttgtatat ccattttcgg
     4021 atctgatcaa gagacaggat gaggatcgtt tcgcatgatt gaacaagatg gattgcacgc
     4081 aggttctccg gccgcttggg tggagaggct attcggctat gactgggcac aacagacaat
     4141 cggctgctct gatgccgccg tgttccggct gtcagcgcag gggcgcccgg ttctttttgt
     4201 caagaccgac ctgtccggtg ccctgaatga actgcaggac gaggcagcgc ggctatcgtg
     4261 gctggccacg acgggcgttc cttgcgcagc tgtgctcgac gttgtcactg aagcgggaag
     4321 ggactggctg ctattgggcg aagtgccggg gcaggatctc ctgtcatctc accttgctcc
     4381 tgccgagaaa gtatccatca tggctgatgc aatgcggcgg ctgcatacgc ttgatccggc
     4441 tacctgccca ttcgaccacc aagcgaaaca tcgcatcgag cgagcacgta ctcggatgga
     4501 agccggtctt gtcgatcagg atgatctgga cgaagagcat caggggctcg cgccagccga
     4561 actgttcgcc aggctcaagg cgcgcatgcc cgacggcgag gatctcgtcg tgacccatgg
     4621 cgatgcctgc ttgccgaata tcatggtgga aaatggccgc ttttctggat tcatcgactg
     4681 tggccggctg ggtgtggcgg accgctatca ggacatagcg ttggctaccc gtgatattgc
     4741 tgaagagctt ggcggcgaat gggctgaccg cttcctcgtg ctttacggta tcgccgctcc
     4801 cgattcgcag cgcatcgcct tctatcgcct tcttgacgag ttcttctgag cgggactctg
     4861 gggttcgaaa tgaccgacca agcgacgccc aacctgccat cacgagattt cgattccacc
     4921 gccgccttct atgaaaggtt gggcttcgga atcgttttcc gggacgccgg ctggatgatc
     4981 ctccagcgcg gggatctcat gctggagttc ttcgcccacc ccaacttgtt tattgcagct
     5041 tataatggtt acaaataaag caatagcatc acaaatttca caaataaagc atttttttca
     5101 ctgcattcta gttgtggttt gtccaaactc atcaatgtat cttatcatgt ctgtataccg
     5161 tcgacctcta gctagagctt ggcgtaatca tggtcatagc tgtttcctgt gtgaaattgt
     5221 tatccgctca caattccaca caacatacga gccggaagca taaagtgtaa agcctggggt
     5281 gcctaatgag tgagctaact cacattaatt gcgttgcgct cactgcccgc tttccagtcg
     5341 ggaaacctgt cgtgccagct gcattaatga atcggccaac gcgcggggag aggcggtttg
     5401 cgtattgggc gctcttccgc ttcctcgctc actgactcgc tgcgctcggt cgttcggctg
     5461 cggcgagcgg tatcagctca ctcaaaggcg gtaatacggt tatccacaga atcaggggat
     5521 aacgcaggaa agaacatgtg agcaaaaggc cagcaaaagg ccaggaaccg taaaaaggcc
     5581 gcgttgctgg cgtttttcca taggctccgc ccccctgacg agcatcacaa aaatcgacgc
     5641 tcaagtcaga ggtggcgaaa cccgacagga ctataaagat accaggcgtt tccccctgga
     5701 agctccctcg tgcgctctcc tgttccgacc ctgccgctta ccggatacct gtccgccttt
     5761 ctcccttcgg gaagcgtggc gctttctcat agctcacgct gtaggtatct cagttcggtg
     5821 taggtcgttc gctccaagct gggctgtgtg cacgaacccc ccgttcagcc cgaccgctgc
     5881 gccttatccg gtaactatcg tcttgagtcc aacccggtaa gacacgactt atcgccactg
     5941 gcagcagcca ctggtaacag gattagcaga gcgaggtatg taggcggtgc tacagagttc
     6001 ttgaagtggt ggcctaacta cggctacact agaagaacag tatttggtat ctgcgctctg
     6061 ctgaagccag ttaccttcgg aaaaagagtt ggtagctctt gatccggcaa acaaaccacc
     6121 gctggtagcg gtggtttttt tgtttgcaag cagcagatta cgcgcagaaa aaaaggatct
     6181 caagaagatc ctttgatctt ttctacgggg tctgacgctc agtggaacga aaactcacgt
     6241 taagggattt tggtcatgag attatcaaaa aggatcttca cctagatcct tttaaattaa
     6301 aaatgaagtt ttaaatcaat ctaaagtata tatgagtaaa cttggtctga cagttaccaa
     6361 tgcttaatca gtgaggcacc tatctcagcg atctgtctat ttcgttcatc catagttgcc
     6421 tgactccccg tcgtgtagat aactacgata cgggagggct taccatctgg ccccagtgct
     6481 gcaatgatac cgcgagaccc acgctcaccg gctccagatt tatcagcaat aaaccagcca
     6541 gccggaaggg ccgagcgcag aagtggtcct gcaactttat ccgcctccat ccagtctatt
     6601 aattgttgcc gggaagctag agtaagtagt tcgccagtta atagtttgcg caacgttgtt
     6661 gccattgcta caggcatcgt ggtgtcacgc tcgtcgtttg gtatggcttc attcagctcc
     6721 ggttcccaac gatcaaggcg agttacatga tcccccatgt tgtgcaaaaa agcggttagc
     6781 tccttcggtc ctccgatcgt tgtcagaagt aagttggccg cagtgttatc actcatggtt
     6841 atggcagcac tgcataattc tcttactgtc atgccatccg taagatgctt ttctgtgact
     6901 ggtgagtact caaccaagtc attctgagaa tagtgtatgc ggcgaccgag ttgctcttgc
     6961 ccggcgtcaa tacgggataa taccgcgcca catagcagaa ctttaaaagt gctcatcatt
     7021 ggaaaacgtt cttcggggcg aaaactctca aggatcttac cgctgttgag atccagttcg
     7081 atgtaaccca ctcgtgcacc caactgatct tcagcatctt ttactttcac cagcgtttct
     7141 gggtgagcaa aaacaggaag gcaaaatgcc gcaaaaaagg gaataagggc gacacggaaa
     7201 tgttgaatac tcatactctt cctttttcaa tattattgaa gcatttatca gggttattgt
     7261 ctcatgagcg gatacatatt tgaatgtatt tagaaaaata aacaaatagg ggttccgcgc
     7321 acatttcccc gaaaagtgcc acctgacgtc gacggatcgg gagatctccc gatcccctat
     7381 ggtgcactct cagtacaatc tgctctgatg ccgcatagtt aagccagtat ctgctccctg
     7441 cttgtgtg
//
