AttB-mCherry

LOCUS       AttB-mCherry             3868 bp DNA     circular SYN 03-AUG-2023
DEFINITION  Envelope protein for producing lentiviral and MuLV retroviral
            particles. Use in conjunction with a packaging vector such as
            pCMV-dR8.2 dvpr (lentiviral) or pUMVC (MuLV retroviral)..
ACCESSION   .
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 3868)
  AUTHORS   Stewart SA, Dykxhoorn DM, Palliser D, Mizuno H, Yu EY, An DS,
            Sabatini DM, Chen IS, Hahn WC, Sharp PA, Weinberg RA, Novina CD
  TITLE     Lentivirus-delivered stable gene silencing by RNAi in primary cells.
  JOURNAL   RNA 2003 Apr;9(4):493-501.
  PUBMED    12649500
REFERENCE   2  (bases 1 to 3868)
  AUTHORS   .
  TITLE     Direct Submission
  JOURNAL   Exported Jul 1, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
COMMENT     SGRef: number: 1; type: "Journal Article"; journalName: "RNA"; date:
            "2003-04"; volume: "9(4)"; pages: "493-501"
FEATURES             Location/Qualifiers
     source          1..3868
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     rep_origin      complement(206..794)
                     /direction=LEFT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
     CDS             complement(965..1825)
                     /codon_start=1
                     /gene="bla"
                     /product="beta-lactamase"
                     /label=AmpR
                     /note="confers resistance to ampicillin, carbenicillin, and
                     related antibiotics"
                     /translation="MSIQHFRVALIPFFAAFCLPVFAHPETLVKVKDAEDQLGARVGYI
                     ELDLNSGKILESFRPEERFPMMSTFKVLLCGAVLSRIDAGQEQLGRRIHYSQNDLVEYS
                     PVTEKHLTDGMTVRELCSAAITMSDNTAANLLLTTIGGPKELTAFLHNMGDHVTRLDRW
                     EPELNEAIPNDERDTTMPVAMATTLRKLLTGELLTLASRQQLIDWMEADKVAGPLLRSA
                     LPAGWFIADKSGAGERGSRGIIAALGPDGKPSRIVVIYTTGSQATMDERNRQIAEIGAS
                     LIKHW"
     promoter        complement(1826..1930)
                     /gene="bla"
                     /label=AmpR promoter
     rep_origin      complement(1956..2411)
                     /direction=LEFT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     primer_bind     2553..2569
                     /label=M13 fwd
                     /note="common sequencing primer, one of multiple similar
                     variants"
     promoter        2579..2597
                     /label=T7 promoter
                     /note="promoter for bacteriophage T7 RNA polymerase"
     misc_feature    2718..2759
                     /label=AttB
     misc_feature    2743..2760
                     /label=Gibson
     misc_feature    2766..2775
                     /label=Kozak sequence
     CDS             2772..3479
                     /codon_start=1
                     /product="monomeric derivative of DsRed fluorescent protein
                     (Shaner et al., 2004)"
                     /label=mCherry
                     /note="mammalian codon-optimized"
                     /translation="MVSKGEEDNMAIIKEFMRFKVHMEGSVNGHEFEIEGEGEGRPYEG
                     TQTAKLKVTKGGPLPFAWDILSPQFMYGSKAYVKHPADIPDYLKLSFPEGFKWERVMNF
                     EDGGVVTVTQDSSLQDGEFIYKVKLRGTNFPSDGPVMQKKTMGWEASSERMYPEDGALK
                     GEIKQRLKLKDGGHYDAEVKTTYKAKKPVQLPGAYNVNIKLDITSHNEDYTIVEQYERA
                     EGRHSTGGMDELYK"
     misc_feature    3483..3488
                     /label=Nhe1
     misc_feature    3488..3505
                     /label=Gibson
     polyA_signal    3541..3662
                     /label=SV40 pA
     primer_bind     complement(3672..3688)
                     /label=M13 rev
                     /note="common sequencing primer, one of multiple similar
                     variants"
     protein_bind    3696..3712
                     /label=lac operator
                     /bound_moiety="lac repressor encoded by lacI"
                     /note="The lac repressor binds to the lac operator to
                     inhibit transcription in E. coli. This inhibition can be
                     relieved by adding lactose or
                     isopropyl-beta-D-thiogalactopyranoside (IPTG)."
     promoter        complement(3720..3750)
                     /label=lac promoter
                     /note="promoter for the E. coli lac operon"
     protein_bind    3765..3786
                     /label=CAP binding site
                     /bound_moiety="E. coli catabolite activator protein"
                     /note="CAP binding activates transcription in the presence
                     of cAMP."
ORIGIN
        1 gaggcggttt gcgtattggg cgctcttccg cttcctcgct cactgactcg ctgcgctcgg
       61 tcgttcggct gcggcgagcg gtatcagctc actcaaaggc ggtaatacgg ttatccacag
      121 aatcagggga taacgcagga aagaacatgt gagcaaaagg ccagcaaaag gccaggaacc
      181 gtaaaaaggc cgcgttgctg gcgtttttcc ataggctccg cccccctgac gagcatcaca
      241 aaaatcgacg ctcaagtcag aggtggcgaa acccgacagg actataaaga taccaggcgt
      301 ttccccctgg aagctccctc gtgcgctctc ctgttccgac cctgccgctt accggatacc
      361 tgtccgcctt tctcccttcg ggaagcgtgg cgctttctca tagctcacgc tgtaggtatc
      421 tcagttcggt gtaggtcgtt cgctccaagc tgggctgtgt gcacgaaccc cccgttcagc
      481 ccgaccgctg cgccttatcc ggtaactatc gtcttgagtc caacccggta agacacgact
      541 tatcgccact ggcagcagcc actggtaaca ggattagcag agcgaggtat gtaggcggtg
      601 ctacagagtt cttgaagtgg tggcctaact acggctacac tagaagaaca gtatttggta
      661 tctgcgctct gctgaagcca gttaccttcg gaaaaagagt tggtagctct tgatccggca
      721 aacaaaccac cgctggtagc ggtggttttt ttgtttgcaa gcagcagatt acgcgcagaa
      781 aaaaaggatc tcaagaagat cctttgatct tttctacggg gtctgacgct cagtggaacg
      841 aaaactcacg ttaagggatt ttggtcatga gattatcaaa aaggatcttc acctagatcc
      901 ttttaaatta aaaatgaagt tttaaatcaa tctaaagtat atatgagtaa acttggtctg
      961 acagttacca atgcttaatc agtgaggcac ctatctcagc gatctgtcta tttcgttcat
     1021 ccatagttgc ctgactcccc gtcgtgtaga taactacgat acgggagggc ttaccatctg
     1081 gccccagtgc tgcaatgata ccgcgagacc cacgctcacc ggctccagat ttatcagcaa
     1141 taaaccagcc agccggaagg gccgagcgca gaagtggtcc tgcaacttta tccgcctcca
     1201 tccagtctat taattgttgc cgggaagcta gagtaagtag ttcgccagtt aatagtttgc
     1261 gcaacgttgt tgccattgct acaggcatcg tggtgtcacg ctcgtcgttt ggtatggctt
     1321 cattcagctc cggttcccaa cgatcaaggc gagttacatg atcccccatg ttgtgcaaaa
     1381 aagcggttag ctccttcggt cctccgatcg ttgtcagaag taagttggcc gcagtgttat
     1441 cactcatggt tatggcagca ctgcataatt ctcttactgt catgccatcc gtaagatgct
     1501 tttctgtgac tggtgagtac tcaaccaagt cattctgaga atagtgtatg cggcgaccga
     1561 gttgctcttg cccggcgtca atacgggata ataccgcgcc acatagcaga actttaaaag
     1621 tgctcatcat tggaaaacgt tcttcggggc gaaaactctc aaggatctta ccgctgttga
     1681 gatccagttc gatgtaaccc actcgtgcac ccaactgatc ttcagcatct tttactttca
     1741 ccagcgtttc tgggtgagca aaaacaggaa ggcaaaatgc cgcaaaaaag ggaataaggg
     1801 cgacacggaa atgttgaata ctcatactct tcctttttca atattattga agcatttatc
     1861 agggttattg tctcatgagc ggatacatat ttgaatgtat ttagaaaaat aaacaaatag
     1921 gggttccgcg cacatttccc cgaaaagtgc cacctaaatt gtaagcgtta atattttgtt
     1981 aaaattcgcg ttaaattttt gttaaatcag ctcatttttt aaccaatagg ccgaaatcgg
     2041 caaaatccct tataaatcaa aagaatagac cgagataggg ttgagtgttg ttccagtttg
     2101 gaacaagagt ccactattaa agaacgtgga ctccaacgtc aaagggcgaa aaaccgtcta
     2161 tcagggcgat ggcccactac gtgaaccatc accctaatca agttttttgg ggtcgaggtg
     2221 ccgtaaagca ctaaatcgga accctaaagg gagcccccga tttagagctt gacggggaaa
     2281 gccggcgaac gtggcgagaa aggaagggaa gaaagcgaaa ggagcgggcg ctagggcgct
     2341 ggcaagtgta gcggtcacgc tgcgcgtaac caccacaccc gccgcgctta atgcgccgct
     2401 acagggcgcg tcccattcgc cattcaggct gcgcaactgt tgggaagggc gatcggtgcg
     2461 ggcctcttcg ctattacgcc agctggcgaa agggggatgt gctgcaaggc gattaagttg
     2521 ggtaacgcca gggttttccc agtcacgacg ttgtaaaacg acggccagtg agcgcgcgta
     2581 atacgactca ctatagggcg aattggagct ccaccgcggt ggcggccgct ctagagagct
     2641 tggcccattg catacgttgt atccatatca taatatgtac atttatattg gctcatgtcc
     2701 aacattaccg ccatgttccg gcttgtcgac gacggcggtc tccgtcgtca ggatcatcca
     2761 agcttgccac catggtgagc aagggcgagg aggataacat ggccatcatc aaggagttca
     2821 tgcgcttcaa ggtgcacatg gagggctccg tgaacggcca cgagttcgag atcgagggcg
     2881 agggcgaggg ccgcccctac gagggcaccc agaccgccaa gctgaaggtg accaagggtg
     2941 gccccctgcc cttcgcctgg gacatcctgt cccctcagtt catgtacggc tccaaggcct
     3001 acgtgaagca ccccgccgac atccccgact acttgaagct gtccttcccc gagggcttca
     3061 agtgggagcg cgtgatgaac ttcgaggacg gcggcgtggt gaccgtgacc caggactcct
     3121 ccctgcagga cggcgagttc atctacaagg tgaagctgcg cggcaccaac ttcccctccg
     3181 acggccccgt aatgcagaag aagaccatgg gctgggaggc ctcctccgag cggatgtacc
     3241 ccgaggacgg cgccctgaag ggcgagatca agcagaggct gaagctgaag gacggcggcc
     3301 actacgacgc tgaggtcaag accacctaca aggccaagaa gcccgtgcag ctgcccggcg
     3361 cctacaacgt caacatcaag ttggacatca cctcccacaa cgaggactac accatcgtgg
     3421 aacagtacga acgcgccgag ggccgccact ccaccggcgg catggacgag ctgtacaagt
     3481 aagctagcgt acaagtaact gcagcgcggg gatctcatgc tggagttctt cgcccacccc
     3541 aacttgttta ttgcagctta taatggttac aaataaagca atagcatcac aaatttcaca
     3601 aataaagcat ttttttcact gcattctagt tgtggtttgt ccaaactcat caatgtatct
     3661 tacgtaatca tgtcatagct gtttcctgtg tgaaattgtt atccgctcac aattccacac
     3721 aacatacgag ccggaagcat aaagtgtaaa gcctggggtg cctaatgagt gagctaactc
     3781 acattaattg cgttgcgctc actgcccgct ttccagtcgg gaaacctgtc gtgccagctg
     3841 cattaatgaa tcggccaacg cgcgggga
//
