pCytERM-smURFP-N1

LOCUS       pCytERM-smURFP-N1              4488 bp DNA     circular SYN 27-MAY-2024
DEFINITION  Vector for fusing EGFP to the C-terminus of a partner protein. For
            other reading frames, use pEGFP-N2 or pEGFP-N3.
ACCESSION   U55762
VERSION     .
KEYWORDS    .
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 4488)
  AUTHORS   Clontech (TaKaRa)
  TITLE     Direct Submission
  JOURNAL   Exported Jun 23, 2026 from SnapGene 6.0.2
            https://www.biofeng.com
FEATURES             Location/Qualifiers
     source          1..4488
                     /lab_host="Mammalian Cells"
                     /mol_type="other DNA"
                     /organism="synthetic DNA construct"
     enhancer        61..364
                     /label=CMV enhancer
                     /note="human cytomegalovirus immediate early enhancer"
     promoter        365..568
                     /label=CMV promoter
                     /note="human cytomegalovirus (CMV) immediate early
                     promoter"
     CDS             615..701
                     /codon_start=1
                     /product="cytochrome P-450 IIC1, partial [Oryctolagus
                     cuniculus]
                     Sequence ID: AAA31436.1Length: 56Number of Matches: 1"
                     /label=cytochrome P-450
                     /translation="MDPVVVLGLCLSCLLLLSLWKQSYGGGKL"
     primer_bind     725..777
                     /label=0222-369-F
     misc_feature    747..752
                     /label=Kozak
     CDS             753..1151
                     /codon_start=1
                     /product="dimeric small ultra-red fluorescent protein
                     derived from a cyanobacterial phycobiliprotein (Rodriguez
                     et al., 2016)"
                     /label=smURFP
                     /translation="MAKTSEQRVNIATLLTENKKKIVDKASQDLWRRHPDLIAPGGIAF
                     SQRDRALCLRDYGWFLHLITFCLLAGDKGPIESIGLISIREMYNSLGVPVPAMMESIRC
                     LKEASLSLLDEEDANETAPYFDYIIKAMS"
     primer_bind     complement(1119..1177)
                     /label=0222-369-R
     polyA_signal    1276..1397
                     /label=SV40 poly(A) signal
                     /note="SV40 polyadenylation signal"
     rep_origin      complement(1404..1859)
                     /direction=LEFT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
     promoter        1886..1990
                     /gene="bla"
                     /label=AmpR promoter
     promoter        1992..2349
                     /label=SV40 promoter
                     /note="SV40 enhancer and early promoter"
     rep_origin      2200..2335
                     /label=SV40 ori
                     /note="SV40 origin of replication"
     CDS             2384..3178
                     /codon_start=1
                     /gene="aph(3')-II (or nptII)"
                     /product="aminoglycoside phosphotransferase from Tn5"
                     /label=NeoR/KanR
                     /note="confers resistance to neomycin, kanamycin, and G418
                     (Geneticin)"
                     /translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGRP
                     VLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDLLS
                     SHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDEEHQ
                     GLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRYQDIA
                     LATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF"
     misc_feature    3410..3457
                     /label=HSV TK poly(A) signal
                     /note="herpesvirus thymidine kinase polyadenylation signal"
     rep_origin      3786..4374
                     /direction=RIGHT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
ORIGIN
        1 tagttattaa tagtaatcaa ttacggggtc attagttcat agcccatata tggagttccg
       61 cgttacataa cttacggtaa atggcccgcc tggctgaccg cccaacgacc cccgcccatt
      121 gacgtcaata atgacgtatg ttcccatagt aacgccaata gggactttcc attgacgtca
      181 atgggtggag tatttacggt aaactgccca cttggcagta catcaagtgt atcatatgcc
      241 aagtacgccc cctattgacg tcaatgacgg taaatggccc gcctggcatt atgcccagta
      301 catgacctta tgggactttc ctacttggca gtacatctac gtattagtca tcgctattac
      361 catggtgatg cggttttggc agtacatcaa tgggcgtgga tagcggtttg actcacgggg
      421 atttccaagt ctccacccca ttgacgtcaa tgggagtttg ttttggcacc aaaatcaacg
      481 ggactttcca aaatgtcgta acaactccgc cccattgacg caaatgggcg gtaggcgtgt
      541 acggtgggag gtctatataa gcagagctgg tttagtgaac cgtcagatcc gctagcgcta
      601 ccggactcag atctatggac cctgtggtgg tgctggggct ctgtctctcc tgtttgcttc
      661 tcctttcact ctggaaacag agctatgggg gagggaagct tcgaattctg cagtcgacgg
      721 taccgcgggc ccgggatcca ccggtcgcca ccatggctaa gacttccgaa cagagggtga
      781 acattgctac actgctgaca gaaaataaga agaaaatcgt ggataaggct tcccaggatc
      841 tgtggcggag acacccagac ctgatcgcac caggaggaat tgctttctct cagagggacc
      901 gcgctctgtg cctgcgagat tacggctggt tcctgcatct gatcaccttt tgtctgctgg
      961 ccggagataa gggccccatc gagtctattg ggctgatcag tattcgagaa atgtataact
     1021 cactgggagt gcccgtccct gcaatgatgg agagcattag atgcctgaaa gaagccagcc
     1081 tgtccctgct ggacgaagag gacgccaacg agaccgcacc ctactttgat tacattatta
     1141 aggctatgag ctaagcggcc gcgactctag atcataatca gccataccac atttgtagag
     1201 gttttacttg ctttaaaaaa cctcccacac ctccccctga acctgaaaca taaaatgaat
     1261 gcaattgttg ttgttaactt gtttattgca gcttataatg gttacaaata aagcaatagc
     1321 atcacaaatt tcacaaataa agcatttttt tcactgcatt ctagttgtgg tttgtccaaa
     1381 ctcatcaatg tatcttaagg cgtaaattgt aagcgttaat attttgttaa aattcgcgtt
     1441 aaatttttgt taaatcagct cattttttaa ccaataggcc gaaatcggca aaatccctta
     1501 taaatcaaaa gaatagaccg agatagggtt gagtgttgtt ccagtttgga acaagagtcc
     1561 actattaaag aacgtggact ccaacgtcaa agggcgaaaa accgtctatc agggcgatgg
     1621 cccactacgt gaaccatcac cctaatcaag ttttttgggg tcgaggtgcc gtaaagcact
     1681 aaatcggaac cctaaaggga gcccccgatt tagagcttga cggggaaagc cggcgaacgt
     1741 ggcgagaaag gaagggaaga aagcgaaagg agcgggcgct agggcgctgg caagtgtagc
     1801 ggtcacgctg cgcgtaacca ccacacccgc cgcgcttaat gcgccgctac agggcgcgtc
     1861 aggtggcact tttcggggaa atgtgcgcgg aacccctatt tgtttatttt tctaaataca
     1921 ttcaaatatg tatccgctca tgagacaata accctgataa atgcttcaat aatattgaaa
     1981 aaggaagagt cctgaggcgg aaagaaccag ctgtggaatg tgtgtcagtt agggtgtgga
     2041 aagtccccag gctccccagc aggcagaagt atgcaaagca tgcatctcaa ttagtcagca
     2101 accaggtgtg gaaagtcccc aggctcccca gcaggcagaa gtatgcaaag catgcatctc
     2161 aattagtcag caaccatagt cccgccccta actccgccca tcccgcccct aactccgccc
     2221 agttccgccc attctccgcc ccatggctga ctaatttttt ttatttatgc agaggccgag
     2281 gccgcctcgg cctctgagct attccagaag tagtgaggag gcttttttgg aggcctaggc
     2341 ttttgcaaag atcgatcaag agacaggatg aggatcgttt cgcatgattg aacaagatgg
     2401 attgcacgca ggttctccgg ccgcttgggt ggagaggcta ttcggctatg actgggcaca
     2461 acagacaatc ggctgctctg atgccgccgt gttccggctg tcagcgcagg ggcgcccggt
     2521 tctttttgtc aagaccgacc tgtccggtgc cctgaatgaa ctgcaagacg aggcagcgcg
     2581 gctatcgtgg ctggccacga cgggcgttcc ttgcgcagct gtgctcgacg ttgtcactga
     2641 agcgggaagg gactggctgc tattgggcga agtgccgggg caggatctcc tgtcatctca
     2701 ccttgctcct gccgagaaag tatccatcat ggctgatgca atgcggcggc tgcatacgct
     2761 tgatccggct acctgcccat tcgaccacca agcgaaacat cgcatcgagc gagcacgtac
     2821 tcggatggaa gccggtcttg tcgatcagga tgatctggac gaagagcatc aggggctcgc
     2881 gccagccgaa ctgttcgcca ggctcaaggc gagcatgccc gacggcgagg atctcgtcgt
     2941 gacccatggc gatgcctgct tgccgaatat catggtggaa aatggccgct tttctggatt
     3001 catcgactgt ggccggctgg gtgtggcgga ccgctatcag gacatagcgt tggctacccg
     3061 tgatattgct gaagagcttg gcggcgaatg ggctgaccgc ttcctcgtgc tttacggtat
     3121 cgccgctccc gattcgcagc gcatcgcctt ctatcgcctt cttgacgagt tcttctgagc
     3181 gggactctgg ggttcgaaat gaccgaccaa gcgacgccca acctgccatc acgagatttc
     3241 gattccaccg ccgccttcta tgaaaggttg ggcttcggaa tcgttttccg ggacgccggc
     3301 tggatgatcc tccagcgcgg ggatctcatg ctggagttct tcgcccaccc tagggggagg
     3361 ctaactgaaa cacggaagga gacaataccg gaaggaaccc gcgctatgac ggcaataaaa
     3421 agacagaata aaacgcacgg tgttgggtcg tttgttcata aacgcggggt tcggtcccag
     3481 ggctggcact ctgtcgatac cccaccgaga ccccattggg gccaatacgc ccgcgtttct
     3541 tccttttccc caccccaccc cccaagttcg ggtgaaggcc cagggctcgc agccaacgtc
     3601 ggggcggcag gccctgccat agcctcaggt tactcatata tactttagat tgatttaaaa
     3661 cttcattttt aatttaaaag gatctaggtg aagatccttt ttgataatct catgaccaaa
     3721 atcccttaac gtgagttttc gttccactga gcgtcagacc ccgtagaaaa gatcaaagga
     3781 tcttcttgag atcctttttt tctgcgcgta atctgctgct tgcaaacaaa aaaaccaccg
     3841 ctaccagcgg tggtttgttt gccggatcaa gagctaccaa ctctttttcc gaaggtaact
     3901 ggcttcagca gagcgcagat accaaatact gtccttctag tgtagccgta gttaggccac
     3961 cacttcaaga actctgtagc accgcctaca tacctcgctc tgctaatcct gttaccagtg
     4021 gctgctgcca gtggcgataa gtcgtgtctt accgggttgg actcaagacg atagttaccg
     4081 gataaggcgc agcggtcggg ctgaacgggg ggttcgtgca cacagcccag cttggagcga
     4141 acgacctaca ccgaactgag atacctacag cgtgagctat gagaaagcgc cacgcttccc
     4201 gaagggagaa aggcggacag gtatccggta agcggcaggg tcggaacagg agagcgcacg
     4261 agggagcttc cagggggaaa cgcctggtat ctttatagtc ctgtcgggtt tcgccacctc
     4321 tgacttgagc gtcgattttt gtgatgctcg tcaggggggc ggagcctatg gaaaaacgcc
     4381 agcaacgcgg cctttttacg gttcctggcc ttttgctggc cttttgctca catgttcttt
     4441 cctgcgttat cccctgattc tgtggataac cgtattaccg ccatgcat
//
